Precautions
1. Do not open the charger. There may be high voltage inside the charger. In case
of a fault, please contact customer service directly.
2. Do not use the charger in the place exposed to direct sunlight or near a heat
source.
3. Do not block the air inlet and outlet during use. The charger should be used in
a dust-free and well-ventilated environment. Keep at least 10cm of space on
both the inlet and outlet sides.
4. Keep children away from the charger when it is being used.
5. Do not use or store flammable and explosive items near the charger.
6. Do not rinse charger directly with water during cleaning. lt is recommended to
wipe it with a clean rag dipped in a small amount of alcohol.
Operation Instructions
1. Please connect the battery to the DC output terminal of the charger first.
Connect the positive (+) pole of the battery to the positive (+) output terminal
and the negative (-) pole of the battery to the negative (-) output terminal.
Never connect the positive (+) pole of the battery to the negative (-) output
terminal, nor the negative (-) pole of the battery to the positive (+) output
terminal. Also, do not connect the positive (+) pole of the battery to the
negative (-) pole of the battery and the positive (+) output terminal to the
negative(-)output terminal simultaneously.
2. Connect the charger to the AC power supply to turn on the charger.
3. Use the "SEL" button to switch to the required charging mode. Note that the
operation should be completed within 60 seconds after power-on.
